LINEAR微功耗升壓穩壓器
發布時間：2022-06-30 16:47:12 瀏覽：1496
LINEAR的微功耗單片升壓轉換器專門針對需要在特輕負荷下最大限度提高工作效率的應用進行了調整。除去極寬的輸入和輸出電壓范圍，LINEAR升壓穩壓器還提供同步整流、集成化肖特基二極管、輸出中斷性能，極大地減少傳輸/輻射EMI。LINEAR微功耗升壓穩壓器是單節堿性或鋰離子電池供電系統元件及其工業生產、醫療設備和汽車應用的理想化選擇。
深圳市立維創展科技是ADI \ LINEAR的代理商，以代理分銷庫存現貨ADI \ LINEAR為產品優勢，可提供當日發貨服務，歡迎咨詢。
詳情了解LINEAR電源模塊請點擊：http://m.liaoyuan999.com/brand/19.html
產品型號 | Number of Outputs | Vin (min) | Vin (max) | Switch Current (typ) | Vout Max (typ) | Isupply (typ) |
|
| V | V | A | V | A |
LT8333 | 1 | 2.8 | 40 | 3 | 40 | 9μ |
LT8334 | 1 | 2.8 | 40 | 5 | 40 | 9μ |
LT8337 | 1 | 2.7 | 28 | 6 | 28 | 4μ |
LT8338 | 1 | 3 | 40 | 1.4 | 40 | 6μ |
LTC7811 | 3 | 1 | 40 | 25 | 10 | 14μ |
LT8336 | 1 | 2.7 | 40 | 3 | 40 | 4μ |
LTC7804 | 1 | 1 | 40 | 25 | 40 | 14μ |
LT8365 | 1 | 2.8 | 60 | 2 | 150 | 9μ |
LTC7818 | 3 | 4.5 | 40 | 25 | 40 | 14μ |
LT8361 | 1 | 2.8 | 60 | 2.5 | 100 | 22μ |
LT8362 | 1 | 2.8 | 60 | 2.5 | 60 | 22μ |
LT8364 | 1 | 2.8 | 60 | 5 | 60 | 9μ |
LTC3897 | 1 | 4.5 | 65 | 30 | 60 | 55μ |
LTC3897-2 | 1 | 4.5 | 65 | 30 | 60 | 55μ |
LT8335 | 1 | 3 | 25 | 2.5 | 28 | 5.5μ |
LT8331 | 1 | 4.5 | 100 | 600m | 140 | 5.5μ |
LT8330 | 1 | 3 | 40 | 1.2 | 60 | 5.5μ |
LT8494 | 1 | 1 | 32 | 2.55 | 70 | 3μ |
LTC3121 | 1 | 500m | 5.5 | 1.8 | 15 | 25μ |
LT8495 | 1 | 1 | 60 | 2.55 | 70 | 9μ |
LTC3769 | 1 | 2.3 | 60 | 25 | 60 | 28μ |
LTC3122 | 1 | 500m | 5.5 | 3.5 | 15 | 25μ |
LTC3786 | 1 | 2.5 | 38 | 30 | 60 | 55μ |
LTC3108-1 | 3 | 20m | 500m | 300m | 4.5 | 6μ |
LT3582 | 2 | 2.475 | 5.5 | 350m | 12 | 325μ |
LT8415 | 1 | 2.2 | 16 | 25m | 40 | 10.5μ |
LTC3526L-2 | 1 | 500m | 5.5 | 750m | 5.5 | 9μ |
LTC3526LB-2 | 1 | 500m | 5.5 | 750m | 5.5 | 250μ |
LTC3528-2 | 1 | 500m | 5.5 | 1.5 | 5.25 | 12μ |
LTC3108 | 3 | 20m | 500m | 300m | 5 | 6μ |
LTC3535 | 2 | 500m | 5 | 750m | 5.25 | 9μ |
LT8410 | 1 | 2.25 | 16 | 25m | 40 | 8.5μ |
LT8410-1 | 1 | 2.25 | 16 | 8m | 40 | 8.5μ |
LT3495 | 1 | 2.2 | 16 | 650m | 40 | 60μ |
LT3495-1 | 1 | 2.2 | 16 | 350m | 40 | 60μ |
LTC3539 | 1 | 500m | 5 | 2.6 | 5.25 | 10μ |
LTC3527 | 2 | 500m | 5 | 800m | 5.25 | 12μ |
LTC3528 | 1 | 500m | 5.5 | 1.5 | 5.25 | 12μ |
LTC3526L | 1 | 500m | 5 | 750m | 5.25 | 9μ |
LTC3537 | 2 | 680m | 5 | 750m | 5.25 | 15μ |
LT3494 | 1 | 2.3 | 16 | 180m | 38 | 65μ |
LT3494A | 1 | 2.3 | 16 | 350m | 38 | 65μ |
LTC3525D-3.3 | 1 | 500m | 4.5 | 450m | 3.3 | 7μ |
LTC3525L-3 | 1 | 500m | 4.5 | 450m | 3 | 7μ |
LTC3422 | 1 | 500m | 4.5 | 2.5 | 5.25 | 25μ |
LTC3525 | 1 | 850m | 4.5 | 450m | 5 | 7μ |
LTC3458L | 1 | 1.4 | 6 | 2.1 | 6 | 12μ |
LTC3499 | 1 | 1.6 | 5.5 | 750m | 6 | 20μ |
LTC3458 | 1 | 1.4 | 6 | 1.6 | 7.5 | 15μ |
LTC3400-1 | 1 | 500m | 5 | 850m | 5 | 19μ |
LT3473 | 1 | 2.2 | 16 | 1.2 | 36 | 100μ |
LT3473A | 1 | 2.2 | 16 | 1.2 | 36 | 100μ |
LTC3459 | 1 | 1.5 | 5.5 | 75m | 10 | 10μ |
LT3463 | 2 | 2.2 | 15 | 250m | 40 | 40μ |
LT3463A | 2 | 2.2 | 15 | 250m | 40 | 40μ |
LTC3421 | 1 | 500m | 4.5 | 4.2 | 5.25 | 12μ |
LTC3425 | 1 | 500m | 4.5 | 7 | 5.25 | 12μ |
LTC3429 | 1 | 500m | 4.4 | 850m | 5 | 20μ |
LT3464 | 1 | 2 | 10 | 80m | 34 | 25μ |
LT1944-1 | 2 | 1.2 | 15 | 175m | 36 | 20μ |
LT1945 | 2 | 1.2 | 15 | 350m | 36 | 20μ |
LTC3423 | 1 | 500m | 5 | 1.6 | 5.5 | 38μ |
LTC3424 | 1 | 500m | 5 | 2.8 | 5.5 | 38μ |
LTC3400 | 1 | 500m | 5 | 850m | 5 | 19μ |
LT1944 | 2 | 1.2 | 15 | 350m | 36 | 20μ |
LTC3401 | 1 | 500m | 5 | 1.6 | 5.5 | 38μ |
LTC3402 | 1 | 500m | 5 | 2.5 | 5 | 38μ |
LT1615 | 1 | 1.2 | 15 | 350m | 36 | 20μ |
LT1615-1 | 1 | 1 | 15 | 100m | 36 | 20μ |
LT1308A | 1 | 1 | 10 | 3 | 34 | 140μ |
LT1308B | 1 | 1 | 10 | 3 | 34 | 2.5m |
LT1610 | 1 | 900m | 8 | 600m | 30 | 30μ |
LT1316 | 1 | 1.5 | 12 | 500m | 30 | 33μ |
LT1307 | 1 | 920m | 12 | 600m | 30 | 50μ |
LT1307B | 1 | 920m | 12 | 600m | 30 | 1m |
