?ADI帶輸出分頻器的壓控振蕩器(VCO)
發布時間：2022-12-09 16:47:20 瀏覽：6315
ADI提供各種帶輸出分壓器選擇的GaAsinGaP異質結雙極性晶體管(HBT)MMICVCO，滿足用戶的應用與設計需求。ADI帶輸出分頻器的壓控振蕩器(VCO)中的集成化諧振器、負變阻器件和變容二極管，都具備優異的相位噪聲性能指標。
應用：
?點到點及點到多點無線通信
?檢測設備和工業控制系統
?SATCOM
?VSAT
?軍工用最終用途
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://m.liaoyuan999.com/brand/25.html
產品型號 | Freq Response RF (min) | Freq Response RF (max) | Freq Output Divider (min) | Freq Output Divider (max) | Phase Noise @ 10k | Phase Noise @ 100k | Output Power (typ) | Vtune (min) | Vtune (max) | Vs (typ) | Is (typ) |
| Hz | Hz | Hz | Hz | dBc/Hz | dBc/Hz |
| V | V | V | A |
HMC1163 | 9.65G | 10.41G | 4.825G | 5.205G | -87 | -114 | 11 dBm | 2 | 13 | 5 | 205m |
HMC1168 | 12.47G | 13.72G | 6.235G | 6.86G | -85 | -113 | 10 dBm | 2 | 13 | 5 | 190m |
HMC1169 | 12.92G | 14.07G | 6.46G | 7.035G | -86 | -113 | 11 dBm | 2 | 13 | 5 | 220m |
HMC1166 | 11.41G | 12.62G | 5.705G | 6.31G | -89 | -115 | 11 dBm | 2 | 13 | 5 | 220m |
HMC1167 | 12.17G | 13.3G | 6.085G | 6.65G | -86 | -113 | 10 dBm | 2 | 13 | 5 | 200m |
HMC1161 | 8.71G | 9.55G | 4.355G | 4.775G | -90 | -115 | 11 dBm | 2 | 13 | 5 | 250m |
HMC1165 | 11.07G | 11.62G | 5.535G | 5.81G | -88 | -113 | 8 dBm | 2 | 13 | 5 | 210m |
HMC1164 | 10.38G | 11.3G | 5.19G | 5.65G | -86 | -114 | 8 dBm | 2 | 13 | 5 | 200m |
HMC1160 | 8.45G | 9.3G | 4.225G | 4.65G | -90 | -116 | 12 dBm | 2 | 13 | 5 | 260m |
HMC1162 | 9.25G | 10.1G | 4.625G | 5.05G | -86 | -115 | 11 dBm | 2 | 13 | 5 | 230m |
HMC734 | 8.6G | 10.2G | 2.15G | 2.55G | -70 | -100 | 18 dBm | 1 | 13 | 5 | 218m |
HMC735 | 10.5G | 12.2G | 2.625G | 3.05G | -75 | -100 | 17 dBm | 1 | 13 | 5 | 217m |
HMC736 | 14.5G | 15G | 7.25G | 7.5G | -80 | -105 | 9 dBm | 1 | 13 | 4.2 | 150m |
HMC737 | 14.9G | 15.5G | 7.45G | 7.75G | -80 | -105 | 9 dBm | 1 | 13 | 4.2 | 150m |
HMC738 | 20.9G | 23.9G | 10.45G | 11.95G | -65 | -95 | 9 dBm | 1 | 13 | 5 | 200m |
HMC739 | 23.8G | 26.8G | 11.9G | 13.4G | -64 | -93 | 8 dBm | 1 | 13 | 5 | 200m |
HMC512 | 9.6G | 10.8G | 4.8G | 5.4G | -85 | -111 | 9 dBm | 2 | 13 | 5 | 330m |
HMC530 | 9.5G | 10.8G | 4.75G | 5.4G | -85 | -110 | 11 dBm | 2 | 13 | 5 | 350m |
HMC582 | 11.1G | 12.4G | 5.55G | 6.2G | -83 | -110 | 9 dBm | 2 | 13 | 5 | 350m |
HMC632 | 14.25G | 15.65G | 7.125G | 7.825G | -80 | -107 | 9 dBm | 2 | 13 | 5 | 350m |
HMC507 | 6.65G | 7.65G | 3.325G | 3.825G | -90 | -115 | 13 dBm | 2 | 13 | 5 | 230m |
HMC508 | 7.3G | 8.2G | 3.65G | 4.1G | -90 | -116 | 15 dBm | 2 | 13 | 5 | 240m |
HMC509 | 7.8G | 8.8G | 3.9G | 4.4G | -90 | -115 | 13 dBm | 2 | 13 | 5 | 250m |
HMC510 | 8.45G | 9.55G | 4.225G | 4.775G | -92 | -116 | 13 dBm | 2 | 13 | 5 | 315m |
HMC511 | 9.05G | 10.15G | 4.525G | 5.075G | -88 | -115 | 13 dBm | 2 | 13 | 5 | 265m |
HMC534 | 10.6G | 11.8G | 5.3G | 5.9G | -82 | -110 | 11 dBm | 2 | 13 | 5 | 350m |
HMC583 | 11.5G | 12.8G | 5.75G | 6.4G | -80 | -110 | 11 dBm | 2 | 13 | 5 | 350m |
HMC584 | 12.5G | 13.9G | 6.25G | 6.95G | -81 | -110 | 10 dBm | 2 | 13 | 5 | 330m |
HMC513 | 10.43G | 11.46G | 5.215G | 5.73G | -85 | -110 | 7 dBm | 2 | 13 | 5 | 275m |
HMC514 | 11.17G | 12.02G | 5.585G | 6.01G | -87 | -110 | 7 dBm | 2 | 13 | 3 | 275m |
HMC515 | 11.5G | 12.5G | 5.75G | 6.25G | -83 | -110 | 10 dBm | 2 | 13 | 5 | 200m |
HMC529 | 12.4G | 13.4G | 6.2G | 6.7G | -83 | -110 | 8 dBm | 2 | 13 | 5 | 260m |
HMC531 | 13.6G | 14.9G | 6.8G | 7.45G | -81 | -110 | 10 dBm | 2 | 13 | 5 | 330m |
HMC533 | 23.8G | 24.8G | 1.4875G | 1.55G | -70 | -95 | 12 dBm | 1 | 13 | 5 | 220m |
