Model

Frequency

Output Characteristics

I (max)

Range

Power (dBm)

dBm/Hz

Flatness (dB)

μV/√Hz

(mA)

NC1101A

10 Hz - 20 kHz

+13

-30

±0.5

7071

70

NC1103A

10 Hz - 500 kHz

+13

-44

±0.5

1414

150

NC1105A

10 Hz - 10 MHz

+13

-57

±.75

316

160

NC1107A

100 Hz - 100 MHz

+13

-67

±1.0

100

160

NC1108A

100 Hz - 500 MHz

+10

-77

±1.5

31.6

160

NC1109A

100 Hz - 1 GHz

+10

-80

±2.0

22.4

160

NC1110A

100 Hz - 1.5 GHz

+10

-82

±2.0

18.2

160

High Crest Factor Modules
50 Ω Load Impedance (Package 3, +15 VDC operation is standard)

Model

Frequency

Output Characteristics

I (max)

Range

Power (dBm)

dBm/Hz

Flatness (dB)

μV/√Hz

(mA)

NC1111A

1 GHz - 2 GHz

-10

-100

±2.0

2.24

250

NC1111B

1 GHz - 2 GHz

0

-90

±2.0

7.07

250

NC1112A

20 MHz - 2 GHz

-10

-103

±2.5

1.58

250

NC1112B

20 MHz - 2 GHz

0

-93

±2.5

5.02

250

NC1113A

10 MHz - 3 GHz

-10

-105

±2.5

1.12

250

NC1113B

10 MHz - 3 GHz

0

-95

±2.5

5.02

250

NC1124A

2 GHz - 4 GHz

-10

-103

±2.5

1.58

250

NC1126A

2 GHz - 6 GHz

-14

-110

±2.5

0.71

250

NC1126B

10 MHz - 6 GHz

0

-98

±3.0

2.8

300

NC1128A

10 MHz - 10 GHz

-17

-117

±3.0

0.32

250

NC1128B

10 MHz - 10 GHz

0

-100

±3.0

2.24

300

NC1120A

10 MHz - 18 GHz

0

-103

±3.0

1.58

500
