PICO電源模塊QPL變壓器
發布時間：2021-10-22 17:00:04 瀏覽：1527
PICO電源模塊的682xx和683xx系列脈沖變壓器致力于滿足QPLMIL–PRF-21038/27標準規定。這些裝置設備嚴格遵守MIL–PRF–21038。PICO電源模塊是MIL–PRF-21038/27-01至-31零部件的供應商。682xx和683xx系列在-55C至+130C的溫度范圍內具備75kHz至1MHz的高輸入阻抗。PICO電源模塊QPL變壓器的壓降最大為20%，過沖最大為1V。共模抑制(CMR)超過45dB。這些裝置設備設計適用于承載從初級到次級的100Vrms，并選用環氧樹脂封裝形式，MSL為3。與往日一樣，PICO電源模塊提供盡可能小的封裝形式和高可靠性。PICO電源模塊有資格對這些變壓器進行M級和T級檢測。
深圳市立維創展科技有限公司是PICO電源模塊公司的代理商。提供原裝進口PICO電源模塊、軍用裝備電源模塊、超高壓電源模塊、小型變壓器、MIL-PRF-21038/27規格變壓器、脈沖變壓器、400MHz電力變壓器、MIL-STD-1553接口變壓器、音頻變壓器、功率電感、微功率電感、電磁干擾電感、薄直流電源控制模塊、軍用裝備DC-DC電源控制模塊、分塊直流電源控制模塊、超高壓直流電源控制模塊、交直流電源控制模塊、開關直流電源控制模塊、隔離器電源模塊、航空電源模塊等功能電源模塊和功率轉換器。進口原裝產品，品質保障，歡迎咨詢。
詳情了解PICO電源模塊請點擊：http://m.liaoyuan999.com/brand/15.html
或聯系PICO的銷售工程師： 0755- 83642657 QQ ： 2295048674
