ADI鎖相環(PLL)頻率合成器和轉換環路
發布時間：2021-01-13 16:17:11 瀏覽：3602
ADI工業領先的鎖相環(PLL)頻率合成器和轉換環路擁有各種高性能、低抖動的時鐘產生和分配設備。鎖相環系列產品有100多種產品，種類繁多，仍在擴展。它們都是針對高數據速率和低抖動時鐘應用而優化的。產品組合包括PLL、PLL/VCO和分配芯片，專為需要同步、時鐘分配和相位噪聲性能的時鐘應用而設計。
ADI在工業領先的PLL集成電路的設計和測試方面有超過25年的經驗。有了業界最完整的PLL產品，我們幾乎可以滿足您的所有PLL需求。
ADI的完全集成的即插即用轉換環(也稱為偏移環)采用系統級封裝(SIP)，在高度抖動敏感的應用中實現頻率合成。與傳統的基于PCB設計的分裂轉換環路方案相比，它可以減少電路板空間，簡化設計。這種高度集成的解決方案采用了具有更高隔離性能的片上電路，可以減少雜散元件，從而縮短上市時間。ADI的轉換環路解決方案為工程師提供頻率合成解決方案，幫助他們開發具有高度競爭力的系統。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
*部分型號需申請出口許可
產品型號 | Freq Response RF (min) | Freq Response RF (max) | Freq Ref Input (max) | 1/f Noise (10kHz Offset at 1GHz Carrier) (typ) | FOM-Normalized Inband PN Int-N (typ) | Is (typ) | Vs+ (min) | Vs+ (max) |
| Hz | Hz | Hz | dBc/Hz | dBc/Hz | A | V | V |
ADF4401A | 62.5M | 8G | 500M |
|
| 676m | 3.15 | 5.25 |
ADF4372 | 62M | 16G | 600M | -127 | -234 | 270M | 3.15 | 3.45 |
ADF41513 | 1G | 26.5G | 800M | -128 | -235 | 74.7m | 3.135 | 3.465 |
ADF4371 | 62.5M | 32G | 600M | -127 | -234 | 260m | 3.15 | 3.45 |
ADF5610 | 57M | 14.6G | 350M | -128 | -229 | 110m | 3 | 3.5 |
ADF5356 | 53.125M | 13.6G | 600M | -121 | -227 | 126m | 3.15 | 5.25 |
ADF4356 | 53.125M | 6.8G | 600M | -121 | -227 | 166m | 3.15 | 3.45 |
ADF4152HV | 500M | 5G | 300M | -113 | -213 | 50m | 3 | 3.6 |
HMC4069 | 10M | 2.9G | 1.3G | -144 | -233 | 295m | 4.75 | 5.25 |
ADF4169 | 500M | 13.5G | 260M | -120 | -224 | 39m | 2.7 | 3.45 |
ADF4355-3 | 51.565M | 6.6G | 600M | -116 | -223 | 146m | 3.1515 | 3.4485 |
ADF4355 | 53.125M | 6.8G | 600M | -116 | -223 | 140m | 3.15 | 3.45 |
ADF4355-2 | 53.125M | 4.4G | 600M | -116 | -223 | 140m | 3.15 | 3.45 |
ADF5355 | 54M | 13.6G | 600M | -116 | -223 | 140m | 3.15 | 3.45 |
HMC832A | 25M | 3G | 350M | -128 | -229 | 219m | 3.1 | 3.5 |
LTC6947 | 350M | 6G | 425M | -134 | -225 | 133m | 3.15 | 3.45 |
LTC6948-1 | 370M | 3.74G | 425M | -134 | -226 | 48m | 3.15 | 3.45 |
LTC6948-2 | 510M | 4.91G | 425M | -134 | -226 | 48m | 3.15 | 3.45 |
LTC6948-3 | 640M | 5.79G | 425M | -134 | -226 | 48m | 3.15 | 3.45 |
LTC6948-4 | 700M | 6.39G | 425M | -134 | -226 | 48m | 3.15 | 3.45 |
ADF4155 | 100M | 600M | 600M | -116 | -223 | 38m | 3.135 | 3.465 |
LTC6950 | 1 | 1.4G | 250M | -134 | -226 | 500m | 3.15 | 3.45 |
ADF4108S | 1G | 7G | 250M |
|
|
| 3.2 | 3.6 |
ADF41020 | 4G | 18G | 400M | -118 | -221 | 30m | 2.85 | 3.15 |
ADF4153A | 500M | 4G | 250M | -121 | -223 | 20m | 2.7 | 3.3 |
HMC835 | 33M | 4.1G | 350M | -128 | -230 | 210m | 3.3 | 5 |
ADF4159 | 500M | 13G | 260M | -120 | -224 | 33m | 2.7 | 3.45 |
HMC1035 | 125M | 2.5G | 350M | -128 | -227 | 210m | 3.15 | 3.5 |
HMC832 | 25M | 3G | 350M | -128 | -229 | 219m | 3.1 | 3.5 |
ADF4351 | 35M | 4.4G | 250M | -118 | -221 | 110m | 3 | 3.6 |
HMC1033 | 25M | 550M | 350M | -128 | -227 | 210m | 3.15 | 3.5 |
HMC698 | 80M | 7G | 1.3G | -151 | -233 | 310m | 4.75 | 5.25 |
HMC1031 | 100k | 500M |
| -112 | -208 | 1.9m | 2.7 | 3.5 |
HMC1032 | 125M | 350M | 350M | -128 | -230 | 190m | 3.3 | 5 |
HMC1034 | 125M | 3G | 350M | -128 | -230 | 190m | 3.3 | 5 |
HMC834 | 45M | 8.4G | 350M | -128 | -230 | 190m | 3.3 | 5 |
ADF4150HV | 10M | 3G | 300M | -123 | -213 | 50m | 3 | 3.6 |
ADF4151 | 500M | 3.5G | 250M | -118 | -221 | 42m | 3 | 3.6 |
ADF4196 | 400M | 6G | 300M | -110 | -216 | 68m | 2.7 | 3.3 |
LTC6946-1 | 373M | 3.74G | 250M | -134 | -226 | 130m | 3.15 | 3.45 |
LTC6946-2 | 513M | 4.91G | 250M | -134 | -226 | 130m | 3.15 | 3.45 |
LTC6946-3 | 640M | 5.79G | 250M | -134 | -226 | 130m | 3.15 | 3.45 |
LTC6946-4 | 700M | 6.39G | 250M | -134 | -226 | 130m | 3.15 | 3.45 |
ADF4150 | 500M | 5G | 250M | -115 | -223 | 50m | 3 | 3.6 |
HMC703 | 10k | 8G | 350M | -130 | -230 | 54m | 2.7 | 3.5 |
HMC767 | 8.45G | 9.55G | 350M | -128 | -230 | 257m | 3.3 | 5 |
HMC829 | 45M | 4.2G | 350M |
| -230 | 190m | 3.3 | 5 |
HMC830 | 25M | 3G | 350M | -128 | -230 | 190m | 3.3 | 5 |
HMC833 | 25M | 6G | 350M | -128 | -230 | 190m | 3.3 | 5 |
LTC6945 | 350M | 6G | 250M | -134 | -226 | 130m | 3.15 | 3.45 |
ADF4158 | 500M | 6.1G | 260M | -110 | -216 | 23m | 2.7 | 3.3 |
HMC704 | 10k | 8G | 350M | -128 | -230 | 52m | 3 | 3.5 |
HMC769 | 9.05G | 10.15G | 350M | -128 | -230 | 272m | 3.3 | 5 |
HMC778 | 9.6G | 10.8G | 350M | -128 | -230 | 272m | 3.3 | 5 |
HMC837 | 1.025G | 4.6G | 200M | -128 | -230 | 141m | 3.3 | 5 |
HMC838 | 795M | 3.78G | 200M | -128 | -229 | 128m | 3.3 | 5 |
HMC839 | 1.05G | 4.82G | 200M | -128 | -229 | 128m | 3.3 | 5 |
HMC840 | 1.31G | 2.83G | 200M | -128 | -230 | 144m | 3.3 | 5 |
ADF4350 | 137.5M | 4.4G | 250M | -111 | -220 | 110m | 3 | 3.6 |
HMC701 | 10k | 8G | 250M |
| -221 | 90m | 3 | 3.45 |
HMC702 | 10k | 14G | 250M |
| -221 | 135m | 3 | 3.45 |
HMC764 | 7.3G | 8.2G | 200M |
| -226 | 245m |
|
|
HMC765 | 7.8G | 8.8G | 200M |
| -226 | 245m |
|
|
HMC783 | 11.5G | 12.5G | 200M |
| -226 | 145m |
|
|
HMC807 | 12.4G | 13.4G | 200M |
| -226 | 205m |
|
|
HMC820 | 1.095G | 5.1G | 200M |
| -229 | 148m | 3.3 | 5 |
HMC821 | 860M | 4.16G | 200M |
| -229 | 148m | 3.3 | 5 |
HMC822 | 665M | 3.3G | 200M |
| -229 | 148m | 3.3 | 5 |
HMC824 | 780M | 870M | 200M |
| -229 | 148m | 3.3 | 5 |
HMC826 | 990M | 1.105G | 200M |
| -229 | 148m | 3.3 | 5 |
HMC828 | 1.285G | 1.415G | 200M |
| -229 | 148m | 3.3 | 5 |
HMC831 | 1.815G | 2.01G | 200M | -128 | -229 | 148m | 3.3 | 5 |
HMC836 | 3.365G | 3.705G | 200M | -128 | -229 | 148m | 3.3 | 5 |
ADF4360-9 | 2M | 200M | 250M |
| -218 | 23m | 3 | 3.6 |
HMC699 | 160M | 7G | 1.3G | -151 | -233 | 310m | 4.75 | 5.25 |
HMC700 | 100k | 8G | 200M |
| -221 | 90m | 2.7 | 3.4 |
ADF4157 | 500M | 6G | 250M | -110 | -211 | 23m | 2.7 | 3.3 |
ADF4113HV | 200M | 3.7G | 150M |
| -212 | 11m | 2.7 | 5.5 |
ADF4156 | 500M | 6.2G | 250M | -110 | -220 | 26m | 2.7 | 3.3 |
ADF4002 | 5M | 400M | 300M | -119 | -222 | 5m | 2.7 | 3.3 |
ADF4108 | 1G | 8G | 250M | -122 | -223 | 15m | 3.2 | 3.6 |
ADF4193 | 400M | 3.5G | 300M | -110 | -216 | 68m | 2.7 | 3.3 |
HMC535 | 14.7G | 15.4G | 240.6M |
| -110 | 340m |
|
|
ADF4360-8 | 65M | 400M | 250M |
| -216 | 35m | 3 | 3.6 |
ADF4360-0 | 2.4G | 2.725G | 250M |
| -216 | 35m | 3 | 3.6 |
ADF4007 | 1G | 7.5G | 240M |
| -219 | 15m | 2.7 | 3.3 |
ADF4154 | 500M | 4G | 250M | -114 | -220 | 20m | 2.7 | 3.3 |
ADF4360-2 | 1.85G | 2.17G | 250M |
| -216 | 35m | 3 | 3.6 |
ADF4360-3 | 1.6G | 1.95G | 250M |
| -216 | 35m | 3 | 3.6 |
ADF4360-4 | 1.45G | 1.75G | 250M |
| -216 | 35m | 3 | 3.6 |
ADF4360-5 | 1.2G | 1.4G | 250M |
| -216 | 35m | 3 | 3.6 |
ADF4360-6 | 1.05G | 1.25G | 250M |
| -216 | 35m | 3 | 3.6 |
ADF4360-7 | 350M | 1.8G | 250M |
| -216 | 37.5m | 3 | 3.6 |
ADF4107 | 1G | 7G | 250M | -122 | -223 | 17m | 2.7 | 3.3 |
ADF4153 | 500M | 4G | 250M | -114 | -223 | 20m | 2.7 | 3.3 |
ADF4360-1 | 2.05G | 2.45G | 250M |
| -216 | 35m | 3 | 3.6 |
HMC440 | 10M | 2.8G | 1.3G | -142 | -233 | 250m | 4.75 | 5.25 |
ADF4212L | 200M | 2.4G | 150M |
| -215 | 7.5m | 2.7 | 3.3 |
ADF4218L | 150M | 3G | 110M |
| -216 | 7m | 2.7 | 3.3 |
ADF4252 | 250M | 3G | 250M |
| -214 | 13m | 2.7 | 3.3 |
ADF4106 | 500M | 6G | 300M | -122 | -223 | 13m | 2.7 | 3.3 |
ADF4001 | 10M | 200M | 104M |
| -217 | 4.5m | 2.7 | 5.5 |
ADF4208 | 80M | 2G | 400M |
| -217 | 14m | 2.7 | 5.5 |
ADF4212 | 60M | 2.7G | 115M |
|
| 13m | 2.7 | 5.5 |
ADF4117 | 100M | 1.2G | 100M |
| -213 | 4.5m | 2.7 | 5.5 |
ADF4110 | 50M | 550M | 104M |
| -213 | 4.5m | 2.7 | 5.5 |
ADF4111 | 80M | 1.2G | 104M |
| -213 | 4.5m | 2.7 | 5.5 |
ADF4112 | 100M | 3G | 104M |
| -215 | 6.5m | 2.7 | 5.5 |
ADF4113 | 200M | 3.7G | 104M |
| -217 | 8.5m | 2.7 | 5.5 |
ADF4116 | 80M | 550M | 100M |
| -211 | 4.5m | 2.7 | 5.5 |
ADF4118 | 100M | 3G | 100M |
| -216 | 6.5m | 2.7 | 5.5 |
AD809 | 155.5M | 155.5M | 19.44M |
|
| 17m | 4.5 | 5.5 |
