?ADI基帶差分低通濾波器
發布時間：2024-01-18 16:52:20 瀏覽：757
低通濾波器能夠通過清除高頻信號的形式來過濾模擬輸入中的高頻噪音或電磁干擾，從而使輸出信號更平穩、效率更高。
ADI固定和可調諧寬帶全差分低通濾波器產品系列兼容諸多的通信網絡、脈沖調制和RFID技術應用，工作帶寬高至25MHz。ADI基帶差分低通濾波器能提供單通道和雙通道電子器件選擇。
產品型號 | Filter Order | Filters Per Package (typ) | Preconfigured | Realization | Fo Max (typ) | Gain Range | Filter |
| order |
|
|
| Hz |
|
|
LTC6601-2 | 2 | 1 | Differential, Lowpass | Pin Configurable | 25M | 1 | 5MHz - 27MHz Low Pass |
LTC6601-1 | 2 | 1 | Differential, Lowpass | Pin Configurable | 25M | 1 | 5MHz - 28MHz Lowpass |
LTC6602 | 9 | 2 | Bandpass, Differential | Elliptic | 900k | 1, 16, 32V/V, 4, 8 | 150kHz - 900kHz Low Pass / Band Pass |
LTC6603 | 9 | 2 | Differential, Lowpass | Elliptic | 2.5M | 0dB, 12dB, 24dB, 6dB | 156kHz - 2.5MHz Low Pass |
LTC6605-10 | 2 | 2 | Differential, Lowpass | Pin Configurable | 14M | 0dB, 12dB, 14dB | 9.7MHz - 14MHz Low Pass |
LTC6605-14 | 2 | 2 | Differential, Lowpass | Pin Configurable | 20M | 0dB, 6dB, 9.5dB | 12.4MHz - 20MHz Low Pass |
LTC6605-7 | 2 | 2 | Differential, Lowpass | Pin Configurable | 10M | 0dB, 12dB, 14dB | 6.5MHz - 10MHz Low Pass |
LT6604-10 | 4 | 2 | Differential, Lowpass | Chebyshev | 10M | Resistor Set | 10MHz Low Pass |
LT6604-15 | 4 | 2 | Differential, Lowpass | Chebyshev | 15M | Resistor Set | 15MHz Low Pass |
LT6604-2.5 | 4 | 2 | Differential, Lowpass | Chebyshev | 2.5M | Resistor Set | 2.5MHz Low Pass |
LT6604-5 | 4 | 2 | Differential, Lowpass | Chebyshev | 5M | Resistor Set | 5MHz Low Pass |
LT6600-15 | 4 | 1 | Differential, Lowpass | Chebyshev | 15M | Resistor Set | 15MHz Low Pass |
LT6600-5 | 4 | 1 | Differential, Lowpass | Chebyshev | 5M | Resistor Set | 5MHz Low Pass |
LT6600-2.5 | 4 | 1 | Differential, Lowpass | Chebyshev | 2.5M | Resistor Set | 2.5MHz Low Pass |
LT6600-10 | 4 | 1 | Differential, Lowpass | Chebyshev | 10M | Resistor Set | 10MHz Low Pass |
LT6600-20 | 4 | 1 | Differential, Lowpass | Chebyshev | 20M | Resistor Set | 20MHz Low Pass |
